Product Details:
|
| Sensor Type: | CMOS | Night Vision: | Yes |
|---|---|---|---|
| Operational Temp: | -25℃～+55℃(-40℃ Optional) | Lens Type: | Fixed |
| Video Format: | H.264 | Interface: | RJ45 |
| Resolution: | 1080p | Fog Penetration: | Optical Filtering |
| Highlight: | AC / DC fog penetration camera,120 Degrees fog penetration camera,Wide Field View fog penetration camera |
||
| Model | HP-DMA6515-2076 |
| Detection | Vehicle: 13km,Human:4.8km |
| Recognition | Vehicle:3.4km,Human: 1.3Km |
| UAV Detection | 1.2km~1.5km (Thermal Camera System) |
| UAV Detection | 3km (Daylight camera system) |
| Thermal sensor | Uncooled Vox sensor, 640*512 resolution |
| Thermal lens | 31~155mm |
| 5X continuous zoom, 8X digital zoom | |
| FOV | Auto focus |
| Image process |
1.Image enhancement: SDE 2.Color: White hot/Black hot 3.Brightness and contrast: 4.AGC, adjustable 5.Digital zoom: 2X/4X 5.Cross: Display 6.Correction: Shutter/Background |
| Visible camera sensor | 1/1.8'' CMOS |
| 0.0002lux super high sensitive color to B/W CCD | |
| 2 megapixels,1920X1080 | |
| Automatic ICR switch | |
| H.264/MPEG4/MIPEG | |
| 32Kbps~16Mbps,60Hz30 FPS | |
| Visible camera lens | 12.5～750mm |
| 60X zoom, auto focus | |
| PTZ structure | U Shape Structure, Two/Three Window design |
| Rotation | Pan: 0~360°, Tilt: +90°～-45° (Support overhead tracking) |
| Speed |
1.Pan speed: 0.01°～60°/s ; Tilt speed: 0.01°~60°/s 2. Acceleration: 100°/s2 Pan; 100°/s2 Tilt 4. Speed adaptive: with intelligent sensing shifting function, support lens focal length speed adaptive function 5. Speed mode: The highest speed mode can be set 6. Drive mode: direct drive with high torque rare earth permanent magnet synchronous motor, high speed start and stop, smooth and smooth tracking with rad |
| PT position |
1. Positioning accuracy: 0.01°- 0.02°, high-frequency fine-tuning pulse precision motor drive, digital angle measurement sensor servo 2. Positioning time: less than 4s |
| Patrol and Scan |
1. Preset: no less than 255 2. Path scanning: support preset point cruise, day and night cruise, line sweep, apple skin scan, scan speed can be set 3. Watch function: support watch preset point line sweep cruise apple skin |
| Data Feedback |
1. Lens servo: support lens field of view, magnification, ZOOM/FOCUS value query, return, positioning function 2. Pan Tilt angle: support horizontal, vertical angle real-time / query return, positioning function |
| Track Mode |
1. Support manual control tracking 2. Support radar linkage automatic tracking 3. Support front-end module automatic tracking 4. Support automatic tracking of back-end software |
| Track Module |
1. Video interface: support visible light/ thermal image video switching tracking 2. Video format: composite video, PAL, NTSC 3. Multi-target detection: support multi-target detection 4. Tracking algorithm: Integrate multiple tracking algorithms, which can be switched manually/automatically according to different scenarios, and support recapture and lock when the target is temporarily lost 5. Target size: adaptive gate, the size of the tracking frame changes automatically according to the target size |
| Enhance |
1. Heating defrost: oriented industrial window defroster, automatic heating temperature control 2. Power failure memory: support, can restore power off state 3. Motor protection: PT blocking protection, high reliability 4. Fault detection: support power-on self-test, status query and fault code feedback 5. Upgrade maintenance: remote restart, remote upgrade function, convenient system maintenance |
| Protocol |
1.TCP / IP, HTTP, DHCP, DNS, DDNS, RTP and other network protocols 2. Support ONVIF2.0 3. Pelco-P, Pelco-D and other industry-standard protocol, baud rate 2400,4800,9600,19200 alternative, proprietary protocols can be customized |
| Power supply | AC90V~305V to DC48V Turntable rotation power can be controlled in 120W Maximum power consumption 180W |
| Environmental Indicators |
1. Working temperature: -40 ℃ ~ + 60 ℃ 2. Storage temperature: -45 ℃ ~ + 70 ℃ 3. Humidity: <90% 4. Protection: IP66 |
Anti-UAV control, low-altitude air defense, military base security monitoring, airport monitoring, oil field and oil depot security.
Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments.
