Product Details:
Place of Origin: China
Brand Name: Hope-Wish
Certification: CE, FCC, ROHS, ISO9001
Model Number: HP-2D-RD7500KU
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 60-180
Payment Terms: L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 50 units per month

advanced integrated Drone Detection Radar Moving Target Surveillance Radar

Description
Frequency: 70MHz-6GHz Full Band Hophopping Number: 4
Detection Range: 5-10km Radial Velocity Range: 0.4m/s-60m/s
Update Rate: 1.2s Distance Accuracy: ≤ 5m
Highlight:

integrated drone detection radars

,

Bird Drone Detection Radar Systems

,

advanced bird drone detection radar systems

Product Description:

Overview:

HP-2D-RD7500KU moving target surveillance radar is designed to detect and track moving targets, including various low RCS and slow moving targets such as pedestrian, vehicles, and vessels. The radar adopts the active phased array and digital pulse compression system, providing accurate target detection, measurement ,and tracking.

With adaptive clutter suppression technology, the radar can effectively filtering out false positives caused by environmental clutter such as trees, crops, clouds, rainwater, and waves.



Key Benefits :

  • Ultra-low false alarm rate
  • Excellent tracking performance under the condition of dense target
  • High detection accuracy
  • Small size, light weight
  • Simultaneous track more than 100 targets
  • 2D radar with azimuth coverage of 90°
  • Operated locally or remotely
  • Independent operation or combination with other radars to achieve 360 ° coverage
  • Ethernet LAN communication (wire or wireless)
  • Active Phased Array
  • Digital Pulse Compression
  • High reliability - full solid-state design


Technical Parameters:



Model HP-2D-RD7500KU
Frequency Ku Band
Frequency hopping number 8



Detection range

≥ 7.5km(human)

Ø≥ 12km(small vehicles)

≥ 20km( ships)

Radial velocity range

0.4m/s-60m/s



Update Rate:



1.2s
Distance accuracy: ≤ 5m
Azimuth accuracy ≤ 0.25°
Velocity accuracy

Ø≤ ± 0.1m/s ± 2%



Azimuth coverage

Ø90 °



Simultaneous tracked targets ≥100
Weight ≤ 5kg
Power consumption

≤ 80W



Power supply range

ØDC 18-28V



Working temperature

-40~+55 ℃



Communication interface

ØGigabit Ethernet



Protection level

IP67



Size((H x W x D)

425 * 300 * 48mm



Applications:

  • Land Border Surveillance
  • Sea Surface Surveillance
  • Fortress Protection
  • Battlefield reconnaissancesign
